Bench Protocols for MG1 China

Version 6.61 of Flex out now

New Flex release out now: download the version 6.61.0.0 and enjoy Bench protocols for MG1 China engine units installed on Asian vehicles such as ChangAn UNI-K and Cirelli 5, equipped with 1,5L and 2,0L turbo petrol engines.

The two engine units that have been added to the vehicle list are:

• MG1UA008
• MG1US008

Try the latest update of Flex, get a taste of Bench protocols for MG1 China and obtain access to Flash and EEPROM memories: elaborate files to enhance engine parameters.

Some of the supported vehicles:

• ChangAn UNI-K 2.0L Turbo 235PS
• Cirelli 3 (G01F) 1.5L Turbo 156PS
• Great Wall Haval (H6) 2.0L Turbo 230PS
• Proton X50 1.5L Turbo 150PS

This new protocol is available for the following software packages:

Bench

• FLS0.1M – SW Flex ECU (car, van, bike) OBD/Bench Master
• FLS0.1S – SW Flex ECU (car, van, bike) OBD/Bench Slave
• FLS0.5M – SW Flex Full Master
• FLS0.5M – SW Flex Full Slave
• FLS0.10M – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Master
• FLS0.10S – SW Flex Bench/Boot Infineon TC17xx / TC2xx / TC3xx Slave

Newly added protocols:

(BENCH)

• All Bosch MG1US008 TC277 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Full Backup
• All Bosch MG1UA008 SPC574 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Full Backup

 Reading Time: ~ 12 minutes         Writing Time: ~ 30 seconds

Bug Fixes:

• Added new CRC type for FCA Bosch MD1CS049
• Added new CRC type for Hino Denso SH72543
• Added new CRC type for FCA Marelli MM10JA
• Added new CRC type for Kia/Hyundai Kefico CPEGD2.20.3
• Added new CRC type for Suzuki Marelli 8DS
• Added new CRC type for Kia/Hyundai Continental Sim2k-341

Software Improvements:

• Added Support for Volvo Bosch ME7.0.1 Boot
