The new solution for Continental MCM and ACM at no additional cost

Flex version 6.27.0.0 out now

Be ready to program Continental MCM2, MCM 2.1 ECUs in Full OBD, Bench, and Boot modes and ACM2.1, ACM2.2 AdBlue Control Modules – installed on the most common Mercedes trucks and buses – in Bench mode.

Flex solution to work on Mercedes trucks and buses now available for free with your subscription, especially available for:

• MCM2.1 D1 OBD Full, Bench and Boot
• MCM2.1 D2 OBD Full, Bench and Boot
• MCM2.1 D3 OBD Full, Bench and Boot
• MCM2.1 D4 OBD Full, Bench and Boot

• MCM2.1 D5 OBD Full, Bench and Boot

• MCM2 D3.1 OBD Full, Bench and Boot
• MCM2 D3.2 OBD Full, Bench and Boot
• ACM2.1 D1 Bench
• ACM2.1 D2 Bench
• ACM2.1 D3 Bench
• ACM2.2 D2 Bench

The peculiarity of these protocols is that no patches are used for programming, thus ensuring that the vehicle’s warranty remains valid. It will only be necessary to write the original full backup of the ECUs to bring them back to their original state.

The new MCM and ACM protocols allow OBD and Bench operations without the need to open the unit.

Moreover, mappacks to modify MCM2 ECUs are available on StageX.

Some of the supported vehicles include:

• Mercedes Truck Actros 1851 12.8L OM471LA 510HP
• Mercedes Truck Arocs 1843 10.7L OM470 428HP
• Mercedes Truck Antos 2532 7.7L OM936 315HP
• Mercedes Bus Citaro C2 10.7L OM470 394HP
• Mercedes Bus Tourismo RHD 12.8L OM471LA 428HP
• Setra S515 HDH 12.8L OM471LA 470HP
• Freightliner Cascadia DD15 14.8L Detroit DD15 530HP

The new protocols are available for the following software packages:
OBD

• FLS0.1M – SW Flex ECU (car, van, bike) OBD + Bench Master
• FLS0.1S – SW Flex ECU (car, van, bike) OBD + Bench Slave
• FLS0.5M – Flex Full SW Package Master
• FLS0.5S – Flex Full SW Package Slave

To program in Full OBD you need to purchase the FLX2.65 cable on www.magicmotorsport.shop or via ticket

Bench

• FLS0.1M – SW Flex ECU (car, van, bike) OBD + Bench Master
• FLS0.1S – SW Flex ECU (car, van, bike) OBD + Bench Slave
• FLS0.5M – Flex Full SW Package Master
• FLS0.5S – Flex Full SW Package Slave
• FLS0.10M – SW Flex Infineon TC17xx / TCxxx Master
• FLS0.10S – SW Flex Infineon TC17xx / TCxxx Slave

Boot

• FLS0.5M – Flex Full SW Package Master
• FLS0.5S – Flex Full SW Package Slave
• FLS0.10M – SW Flex Infineon TC17xx / TCxxx Master
• FLS0.10S – SW Flex Infineon TC17xx / TCxxx Slave

Newly added protocols:
(OBD Full)

• Mercedes Trucks/Bus Continental MCM2 D3.1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2 D3.2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D1 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D2 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D3 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D4 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D5 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup

Read time: ~ 1.30 minutes  Write time: ~ 2 minutes

(Bench)

• Mercedes Trucks/Bus Continental MCM2 D3.1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2 D3.2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D1 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D2 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D3 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D4 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D5 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.1 D3 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental ACM2.2 D2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup

Read time: ~ 1.30 minutes  Write time: ~ 2 minutes

(Boot)

• Mercedes Trucks/Bus Continental MCM2 D3.1 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks Continental MCM2 D3.2 TC1796 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D1 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D2 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D3 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D4 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup
• Mercedes Trucks/Bus Continental MCM2.1 D5 TC1797 Read/Write/Checksum Calculation Internal Flash, Read/Write Internal EEPROM, Read/Write External EEPROM, Full Backup

Read time: ~ 1.30 minutes  Write time: ~ 2 minutes
