Magic Motorsport tool update: Flex 4.1.0.0

With the release of the new Magic Motorsport tool update Flex 4.1.0.0 there are new OBD solutions to program Magneti Marelli ECUs. Thanks to this new update, Flex today allows you to work on Marelli 8 and Marelli 9 ECUs, mounted on FCA group vehicles.

OBD solutions for Marelli 8 and Marelli 9 ECUs

Furthermore, ECUs such as SID208, SID209, SID211 and SID807EVO used in Ford and PSA groups will be supported as well in OBD & Bench modes. New Bench protocols are also available for BOSCH MG1CS163 (Bentley) and DCU17CV51 (for JCB Tractors).

Protocols are still being transferred from MAGPro2 X17 to Flex and with version 4.1.0.0 the OBD remapping solutions for Marelli have been improved as well as those for EDC15 VAG, EDC16 BMW, SAGEM S3000, Delphi DCM1.2 and DCM3.4 (Renault Nissan Dacia group).

New protocols added:

• Alfa Romeo Marelli 8DF OBD: Virtual Read/Read/Write/Checksum Maps
• Alfa Romeo Marelli 8F2 OBD: Virtual Read/Read/Write/Checksum Maps
• Alfa Romeo Marelli 8F3 OBD: Virtual Read/Read/Write/Checksum Maps
• Alfa Romeo Marelli 9DF OBD: Virtual Read/Read/Write/Checksum Maps
• Alfa Romeo Marelli 9GF OBD: Virtual Read/Read/Write/Checksum Maps
• Audi Bosch EDC15P OBD: Read/Write/Checksum Maps
• Audi Bosch EDC15V OBD: Read/Write/Checksum Maps
• Audi Bosch EDC15VM OBD: Read/Write/Checksum Maps
• Bentley Bosch MG1CS163 Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Backup/Restore
• BMW Bosch EDC16C1 OBD: Read/Write/Checksum Maps
• BMW Bosch EDC16C31 OBD: Read/Write/Checksum Maps
• BMW Bosch EDC16C35 OBD: Read/Write/Checksum Maps
• BMW Bosch EDC16CP35 OBD: Read/Write/Checksum Maps
• Buick Delco E80 Boot: Read/Write/Checksum Internal Flash
• Cadillac Delco E80 Boot: Read/Write/Checksum Internal Flash
• Chevrolet Delco E80 Boot: Read/Write/Checksum Internal Flash
• Citroen Continental SID208 OBD: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore, Virgin
• Citroen Continental SID208 Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore, Virgin
• Citroen Delphi DCM3.4 OBD: Read/Write/Checksum Maps
• Citroen Marelli 8DF OBD: Virtual Read/Read/Write/Checksum Maps
• Citroen Marelli 8F3 OBD: Virtual Read/Read/Write/Checksum Maps
• Citroen Marelli 9DF OBD: Virtual Read/Read/Write/Checksum Maps
• Dacia Delphi DCM1.2 OBD: Read/Write/Checksum Maps
• Dacia Delphi DCM3.4 OBD: Read/Write/Checksum Maps
• Dodge Bosch EDC17C79 OBD: Virtual Read/Read/Write/Checksum Maps
• Fiat Bosch EDC17C49 OBD: Virtual Read/Read/Write/Checksum Maps
• Fiat Bosch EDC17C84 OBD: Read/Write/Checksum Maps
• Fiat Bosch EDC17C84 Bench: Read/Write/Checksum Internal Flash, Read/Write/Checksum Internal EEPROM, Full Read/Full Write Clone/Restore
• Fiat Bosch EDC17C84 Boot: Read/Write/Checksum Internal Flash, Read/Write/Checksum Internal EEPROM, Full Read/Full Write Clone/Restore
• Fiat Continental SID208 OBD: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore, Virgin
• Fiat Continental SID208 Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore, Virgin
• Fiat Marelli 8DF OBD: Virtual Read/Read/Write/Checksum Maps
• Fiat Marelli 8F2 OBD: Virtual Read/Read/Write/Checksum Maps
• Fiat Marelli 8F3 OBD: Virtual Read/Read/Write/Checksum Maps
• Fiat Marelli 9DF OBD: Virtual Read/Read/Write/Checksum Maps
• Fiat Marelli 9GF OBD: Virtual Read/Read/Write/Checksum Maps
• Ford Continental EMS2303 Boot: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Ford Continental SID208 OBD: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Ford Continental SID208 Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Ford Continental SID208 Boot: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Ford Continental SID209 OBD: Read/Write/Checksum Internal Flash, Read/Write Internal 9EEPROM, Full Read/Full Write Clone/Restore (except Ranger)
• Ford Continental SID209 Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore (except Ranger)
• Ford Continental SID209 Boot: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Ford Continental SID211 OBD: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Ford Continental SID211 Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Ford Continental SID211 Boot: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Ford Continental SID807EVO OBD: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Ford Continental SID807EVO Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Ford Continental SID807EVO Boot: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Ford Marelli 9GF OBD: Virtual Read/Read/Write/Checksum Maps
• Ford Siemens SID202 OBD: Read/Write/Checksum Maps
• Ford Siemens SID803 OBD: Read/Write/Checksum Maps
• Ford Siemens SID803A OBD: Read/Write/Checksum Maps
• GMC Delco E80 Boot: Read/Write/Checksum Internal Flash
• Holden Delco E80 Boot: Read/Write/Checksum Internal Flash
• Jaguar Bosch MED17.0 Bench: Read/Write/Checksum Internal Flash, Read/Write/Checksum Internal EEPROM, Full Read/Full Write Clone/Restore
• Jaguar Bosch MED17.0 Boot: Read/Write/Checksum Internal Flash, Read/Write/Checksum Internal EEPROM, Full Read/Full Write Clone/Restore
• JCB Bosch DCU17CV51 Bench: Read/Write/Checksum Internal Flash, Read/Write/Checksum Internal EEPROM, Full Read/Full Write Clone/Restore
• JCB Bosch DCU17CV51 Boot: Read/Write/Checksum Internal Flash, Read/Write/Checksum Internal EEPROM, Full Read/Full Write Clone/Restore
• Jeep Bosch EDC17C49 OBD: Virtual Read/Read/Write/Checksum Maps
• Jeep Bosch EDC17C79 OBD: Virtual Read/Read/Write/Checksum Maps
• Lancia Bosch EDC17C49 OBD: Virtual Read/Read/Write/Checksum Maps
• Lancia Marelli 8DF OBD: Virtual Read/Read/Write/Checksum Maps
• Lancia Marelli 8F3 OBD: Virtual Read/Read/Write/Checksum Maps
• Lancia Marelli 9DF OBD: Virtual Read/Read/Write/Checksum Maps
• Lancia Marelli 9GF OBD: Virtual Read/Read/Write/Checksum Maps
• Land Rover Bosch MED17.0 Bench: Read/Write/Checksum Internal Flash, Read/Write/Checksum Internal EEPROM, Full Read/Full Write Clone/Restore
• Land Rover Bosch MED17.0 Boot: Read/Write/Checksum Internal Flash, Read/Write/Checksum Internal EEPROM, Full Read/Full Write Clone/Restore
• Land Rover Continental SID208 OBD: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Land Rover Continental SID208 Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Land Rover Continental SID208 Boot: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Lexus Denso 275036-3410 AUD: Read/Write/Checksum Internal Flash, Read/Write External EEPROM, Full Read/Full Write Clone/Restore
• Maserati Bosch EDC17C79 OBD: Virtual Read/Read/Write/Checksum Maps
• Mazda Continental SID208 OBD: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Mazda Continental SID208 Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Mazda Continental SID208 Boot: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Mazda Continental SID807EVO OBD: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Mazda Continental SID807EVO Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Mazda Continental SID807EVO Boot: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Mini Bosch EDC16C35 OBD: Read/Write/Checksum Maps
• New Holland Bosch EDC17CV41 Bench: Read/Write/Checksum Internal Flash, Read/Write/Checksum Internal EEPROM, Full Read/Full Write Clone/Restore
• New Holland Bosch EDC17CV41 Boot: Read/Write/Checksum Internal Flash, Read/Write/Checksum Internal EEPROM, Full Read/Full Write Clone/Restore
• Nissan Delphi DCM1.2 OBD: Read/Write/Checksum Maps
• Nissan Delphi DCM3.4 OBD: Read/Write/Checksum Maps
• Opel Delco E80 Boot: Read/Write/Checksum Internal Flash
• Opel Marelli 8F3 OBD: Virtual Read/Read/Write/Checksum Maps
• Peugeot Bosch EDC17C49 OBD: Virtual Read/Read/Write/Checksum Maps
• Peugeot Continental SID208 OBD: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore, Virgin
• Peugeot Continental SID208 Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore, Virgin
• Peugeot Delphi DCM3.4 OBD: Read/Write/Checksum Maps
• Peugeot Marelli 8DF OBD: Virtual Read/Read/Write/Checksum Maps
• Peugeot Marelli 8F3 OBD: Virtual Read/Read/Write/Checksum Maps
• Peugeot Marelli 9DF OBD: Virtual Read/Read/Write/Checksum Maps
• Renault Delphi DCM1.2 OBD: Read/Write/Checksum Maps
• Renault Delphi DCM3.4 OBD: Read/Write/Checksum Maps
• Renault Getrag DC4 Boot: Read/Write/Checksum Internal Flash, Read/Write/Checksum Internal EEPROM, Full Read/Full Write Clone/Restore
• Renault Sagem S3000 OBD: Read/Write/Checksum Maps
• Renault Valeo V40 OBD: Read/Write/Checksum Maps
• Renault Valeo V42 OBD: Read/Write/Checksum Maps
• Seat Bosch EDC15P OBD: Read/Write/Checksum Maps
• Seat Bosch EDC15V OBD: Read/Write/Checksum Maps
• Skoda Bosch EDC15P OBD: Read/Write/Checksum Maps
• Skoda Bosch EDC15V OBD: Read/Write/Checksum Maps
• Skoda Bosch EDC15VM OBD: Read/Write/Checksum Maps
• Suzuki Bosch EDC17C49 OBD: Virtual Read/Read/Write/Checksum Maps
• Suzuki Delphi DCM1.2 OBD: Read/Write/Checksum Maps
• Toyota Denso 275036-3410 AUD: Read/Write/Checksum Internal Flash, Read/Write External EEPROM, Full Read/Full Write Clone/Restore
• Vauxhall Delco E80 Boot: Read/Write/Checksum Internal Flash
• Vauxhall Marelli 8F3 OBD: Virtual Read/Read/Write/Checksum Maps
• Volkswagen (VW) Bosch EDC15P OBD: Read/Write/Checksum Maps
• Volkswagen (VW) Bosch EDC15V OBD: Read/Write/Checksum Maps
• Volkswagen (VW) Bosch EDC15VM OBD: Read/Write/Checksum Maps
• Volvo Continental SID807EVO OBD: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Volvo Continental SID807EVO Bench: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore
• Volvo Continental SID807EVO Boot: Read/Write/Checksum Internal Flash, Read/Write Internal EEPROM, Full Read/Full Write Clone/Restore

Bugfixes:

• GM Delco E80 OBD: fixed a writing issue
• Land Rover Siemens SID203V8 OBD: fixed a writing issue
• Mazda Denso SHxx OBD: writing issue fixed
• Mitsubishi Denso SH72543 OBD & Bench: fixed an identification issue
• Porsche Continental SDI10.3 Boot: added new CRC
• Renault Bosch EDC17C84 OBD: fixed a reading issue
• VAG Continental Simos 8.6 Boot: unlock issue fixed
• VAG Continental Simos PCR2.1 Boot: fixed an issue with writing EEPROM

ECU programming software improvements:

• BMW Bosch MD1CP032 Bench: added new CRC
• GM Delco E80 OBD & Boot: added new CRC
• GM Delco E98 (MY2019) OBD & Bench: added new CRC
• JLR Bosch EDC17CP55 OBD: fixed a reading issue
• Mitsubishi (L200 MY2020) Denso SH72543 OBD & Bench: added new CRC
• New Holland Bosch MD1CE101 Bench: added new CRC
• Renault (Trafic MY2019) Bosch MD1CS006 Bench: added new CRC
• VAG Bosch MD1CP004 OBD & Bench: Added new CRC
• Volvo Denso MB279700-96xx Bench: protocol checksum logic improved
