ECM TITANIUM – Drivers

ECM Titanium drivers updated on Continental SIMOS10 and SIMOS18 equipped on VAG vehicles. Remapping at the highest level.

Drivers Update on Continental SIMOS10 and SIMOS18 equipped on Audi, Seat, Skoda and Volkswagen.

The Alientech team that deals with the Drivers update focused on the CONTINENTAL SIMOS10 and CONTINENTAL SIMOS18 equipped on Audi, Seat, Skoda and Volkswagen vehicles. Find out what you can get thanks to ECM Titanium and the updated maps that you will find in the Drivers!

• CONTINENTAL SIMOS10
• CONTINENTAL SIMOS18

The management of these ECU's – Continental SIMOS10 and SIMOS18 – is a bit more complex than the Bosch management, as it requires the modification of some particular maps in order to prevent the vehicle from going in recovery mode or having problems related to correct operation.

• MAXIMUM / MINIMUM DIFFERENCE FOR TOO HIGH / LOW ENGINE LOAD
• TEMPERATURE DIFFERENCE FOR TURBINE PROTECTION
• TURBO PRESSURE LIMITER FOR LAUNCH CONTROL MODE
• POP & BANG

SIMOS10

AUDI

• Audi A1 1.2 TFSI 86 – 105CV
• Audi A3 1.2 TFSI 105Cv

SEAT

• Ibiza 1.2 TSI 86 – 105CV
• Seat Leòn 1.2 TSI 105CV

SKODA

• Fabia 1.2 TSI 86 – 105CV
• Roomster 1.2 TSI 105CV
• Yeti 1.2 TSI 105CV

VOLKSWAGEN

• Golf 1.2 TSI 86 – 105CV
• Polo 1.2 TSI 86 – 105CV
• Beetle 1.2 TSI 105CV
• Jetta 1.2 TSI 105CV

SIMOS18

AUDI

• S3 2.0 TFSI QUATTRO 310CV
• S1 2.0 TFSI QUATTRO 230CV

SEAT

• Leon Cupra 2.0 TSI 300CV
• Ibiza Cupra 1.8 TSI 190CV

SKODA

• Octavia VRS 2.0 TSI 245CV – 230CV

VOLKSWAGEN

• Golf GTI 2.0 TSI 230CV
• Golf GTI PERFORMANCE 2.0 TSI 245CV
• Polo GTI 1.8 TSI 190CV
• Beetle 2.0 TSI 220CV

CONTINENTAL SIMOS10 - SIMOS18

Driver for ECM Titanium

During the massive update of these drivers, the focus was in particular on the Pop & Bang maps and some other maps.

MAXIMUM / MINIMUM DIFFERENCE FOR TOO HIGH / LOW ENGINE LOAD

These are control maps related to a turbocharger protection threshold, cutting the pressure when an overpressure is detected in the intake manifold.

TEMPERATURE DIFFERENCE FOR TURBINE PROTECTION
It is the maximum temperature difference above a set maximum turbine temperature threshold, beyond which the turbine protection is activated.

TURBO PRESSURE LIMITER FOR LAUNCH CONTROL MODE
It is a map that manages the pressure target when Launch Control mode is active.

POP & BANG
In order to obtain burble effect on driver there are specific maps that will allow to customize all the factors related to Pop & Bang (duration, loudness, delay in activation and gear shift crackles).

The main maps needed to make Burble work properly are the minimum spark advance: with these maps you’ll be able to manage the volume of the bangs from the exhaust: the more you will decrease them, the louder will be the car. Obviously, you need to work on the lift off area (high revs and low load).

With this new update you’ll be also able to manage in what driving modes enable the pop & bang function: thanks to the single point activation you’ll be able to decide on what driving mode enable the effect.

Generally Pop & Bang raise the temperature of the catalyst and turbine, so in order to protect the components of the car there is a time reduction factor in function of the catalyst temperature that will reduce the time the burble effect is active in order to allow the turbocharger and the catalyst to cool down. Cooler components mean less risk to break down!
